BR-6641 User Manual
58
Source Any address
LAN
Local host
IP Address
IP Range
Subnet
<Named IP
addresses>
< IP Grouping >
Packets sent from the specified source will be matched:
Any Address: Match all packets regardless of its source.
LAN: Match all packets that come from the LAN.
Localhost: Match all packets that come from BR-6641
Localhost.
IP Address: Match packets from a single IP address. e.g.
192.168.1.4.
IP Range: Match packets from a continuous range of IP
addresses. e.g. 192.168.1.10-192.168.1.20
Subnet: Match packets that come from a subnet. e.g.
192.168.1.0/255.255.255.0
Named IP addresses: If you predefined IP groups in
Chapter 3 [System]→[Named IP Grouping], their group
name will be shown in the list.
IP Grouping: If you predefined IP groups in Chapter 3
[System]→[IP Grouping], their Group Name will be shown in
the list.
Destination Any address
WAN
Local host
IP Address
IP Range
Subnet
<Named IP
addresses>
< IP Grouping >
Packets sent from the specified destination will be matched:
Any Address: Match all packets regardless of its source.
WAN: Match all packets that come from the WAN.
Localhost: Match all packets that come from BR-6641
Localhost.
IP Address: Match packets from a single IP address. e.g.
192.168.1.4.
IP Range: Match packets from a continuous range of IP
addresses. e.g. 192.168.1.10-192.168.1.20
Subnet: Match packets that come from a subnet. e.g.
192.168.1.0/255.255.255.0
Named IP addresses: If you predefined IP groups in
Chapter 3 [System]→[Named IP Grouping], their group
name will be shown in the list.
IP Grouping: If you predefined IP groups in Chapter 3
[System]→[IP Grouping], their Group Name will be shown in
the list.
Service FTP(21)
SSH (22)
TELNET(23)
SMTP(25)
POP3(110)
H323 (1720)
Protocol Number
ICMP@
TCP@
The services, which are predefined in [Service Name], will
be matched. For example:
FTP(21): The packets, whose predefined TCP port number
in [Service Name] is 21, are to be match.
Protocol Number: Define the Protocol Number, then the
packets with the Protocol Number are to be defined.
ICMP @: Define the Type value, then the packets, whose
ICMP take this Type value, will be defined.
TCP/UDP @: The TCP/UDP service type to be matched.
You can select the matching criteria from the publicly known
