BR-6641 User Manual
59
UDP@
< Service Grouping
Name>
Any
service types (e.g. FTP), or you can choose the port number
in TCP/UDP packet. To specify a range of port numbers,
type starting port number plus hyphen “-“and ending port
number. e.g. “TCP@123-234”.
Group: The packets from the group which are predefined in
[Service Grouping].
Any: All packets are to be matched
Algorithm Fixed
By Weight
By Traffic
Algorithm for Auto Routing:
1. Fixed: Only route the connections on a fixed WAN link.
2. By Weight: Input the weight to route the connections to
WAN link according to weight..
3. By Traffic: Route the connection to the WAN link
according to total traffic. Connection will be route to the
link which has more remained bandwidth.
Parameter <select WAN link(s)
for the algorithm, or
put a weight on each
WAN link>
The type of parameter depends on the algorithm you
choose.
The number represents the number of WAN link. You can
check, the check box under the number, telling BR-6641
to apply the algorithm to this WAN link.
L Enable
Disable
Enable: The logging will be enabled. Whenever the rule is
matched, the system will write the event to the log file.
Disable: No log will be generated.
Table 4.2 The Description of the Fields in the Auto Routing Policy Table
