4 EdimaxTechnology(UK)Limited|QuickInstallationGuide(EW‐7206APg)

www.edimax.co.uk



Step3:ConfiguretheAccessPoint

1. Inthecomputer,clickonControlPanel,NetworkConnection,Right‐clickonLocal

AreaConnection,gotoit'sProperties.

2. SelectInternetProtocol(TCP/IP),clickonProperties.

3. SelectObtainIPAddressAutomaticallyandclickOKtosavethesetting.



4. Connectthecomputertotherouter.

5. ConnectEW‐7206APgwithaLANcabletotherouter.



    



LANcable

LANcable

Router:

2.1

.2.1

EW‐7206APg:

192.168.2.50

Other manuals for Edimax EW-7206APg

Questions and Answers:

Need help?

Do you have a question about the Edimax EW-7206APg and is the answer not in the manual?

General

2.4 GHz	Yes
Frequency band	2.4 - 2.4835 GHz
Maximum data transfer rate	100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Security algorithms	EAP-MD5, SSID, WPA, WPA2
Compliance industry standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.3u
Flash memory	2 MB
Internal memory	8 MB
Processor model	Realtek RTL8186
Antenna connector type	RP-SMA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC Class B, CE Mark
Power requirements	12V DC, 0.4A
