Edimax EW-7416APn v2 Quick Installation Guide

11
Repeater Mode
Position the device in a location for optimal wireless extension, such as the
middle of your house. You can connect to the device wirelessly by searching
and connecting to the device name you set up.
Appendix
How to Find Your Network Security Key
Note: These instructions are for Windows 7/Vista. If
you are using Windows XP or earlier, you need to
contact the manufacturer or ISP.
1. Open “Control Panel”
and click “Network and
Internet” in the top
menu.
2. Click on “View network
status and tasks” which is
under the heading
“Network and Sharing
Center”.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
