Edwards AB4G

6 / 6 P/N 3100672-EN • REV 07 • ISS 23JAN14
Figure 6: Synchronized alarm signaling application
(1) Data from signature controller
(2) Use a 24 VDC primary or auxiliary power supply that is UL/ULC Listed for fire protective signaling systems
(3) Listed 24 V EOL supervising equipment
3
AB4G
SLC 
SLC 
AB4G
AUX  _RISER
AUX
 _RISER
1
2
