SIGA-REL fault messages on EST2 panels
WARNING: Disconnect all wiring on TB4 of the SIGA-REL (release circuits 1
and 2) when servicing the system. Disabling points does not prevent activation of
the release circuits. Failure to follow these instructions may result in loss of life,
serious injury, or property damage.
After the successful completion of the programming process, the fire alarm
control panel resets itself. Upon reset, device supervision may cause the panel to
generate a Dev/Line fault for each SIGA-REL circuit. This is a normal indication,
and it should go away within minutes. Table 21 lists the indications you may see
for the SIGA-REL on the 2-LCD.
Table 21: SIGA-REL fault messages
Device
Condition
LED
2-LCD message
Abort
Short
Monitor
None, unless there is another event
Open
Trouble
Open Fault
Abort [1]
Manual
Short
Alarm
1st Fire Alarm
Manual [1]
Open
Trouble
Open Fault
Manual [1]
Prerelease_1
Short
Trouble
Short Fault
Prerelease_1 [1]
Open
Trouble
Open Fault
Prerelease_1 [1]
Prerelease_2
Short
Trouble
Dev/Line Flt
Prerelease_2 [1]
Open
Trouble
Open Fault
Prerelease_2 [1]
Abort
Manual
Prerelease_1
Prerelease_2
Release_1
Release_2
No riser
Trouble
Dev/Line Flt
Device (Abort, Manual, Prerelease_1,
Prerelease_2, Release_1, or Release_2) [1]
Release_1
Short
Trouble
Short Fault
Release_1 [1]
Open
Trouble
Open Fault
Release_1 [1]
Release_2
Short
Trouble
Dev/Line Flt
Release_2 [1]
