EFA 57 - Machine Overview

Pneumatically operated breastbone saw EFA 57
Operating instructions EN
Part no. 110 885 700 – Rev.00 – 01.2020 13 of 34
Machine overview
No. Part description No. Part description
1
Saw blade (78 teeth)
8
Supply air connection
2
Guide plate
9
Exhaust air connection
3
Keep-off rail
10
Sound absorber
4
Slider edge (2x)
11
Guide with holes for spring balancer
5
Threaded pin for slider adjustment
12
Tapered handle
6
Housing complete
13
Grease nipple
7
Handle with valve lever
Pneumatically operated breastbone saw EFA 57
10
1
2
3
4
7
6
5
9
8
11
12
13
