Pneumatically operated breastbone saw EFA 57
Operating instructions EN
Part no. 110 885 700 – Rev. 00 – 01.2020
22 of 34
Loosen hexagon screws (1) with socket wrench (accessory) and remove them together with washer (2).
Pull the saw blade out of guide (3) and keep-off rail (4).
Change saw blade. Insert the new saw blade into the guide (3) and push it back until the screws on the
slider (5) can be inserted again.
Tighten the hexagon screws (1) together with washer (2) using a socket wrench. Observe the tightening
torque of 20 Nm.
Connect the EFA pneumatically operated breastbone saw to the compressed air supply and carry out a
test run.
Check guide.
1
2
3
5
4
