pag. 30
BRUSCHCUTTERS DS 2200 - DS 2400
Workshop manual
8. CLUTCH
CLUCTH
Remove the two shoulder bolts
Remember the order for the spacers and washers when
removing the clutch shoes.
2 on each bolt under the clutch and the thinner under
the head of the bolt.
Check the clutch shoes for wear it should be changed if
less than 0,8 mm (.030”).
Check the clutch drum for discoloration and wear. Change
if necessary (changed if less than 2 mm (.080”)).
1.
2.
3.
4.
