Connections in Solar accumulator
15
1 Charging-Expansion 1 1/4” 9 Cold domestic water 22mmcu
2 Domestic water 22mm cu 10 Drain cock 1/2”
3 Warm water to radiators 1 1/4” 11 Water to solar panels 18mm cu
4 Connect to nr6 22mm cu 12 Thermometers 1/2”
5 Electrical heater 2” 13 Connection/Return radiators 1”
6 Connect to nr4 22mm cu 14 Water from solar panels 18mm cu
7 Allternativ return from radiators 1” 15 Sensor solar 1/2”
8 Sensor solar 1/2” 16 Alternative sensor 1/2”
16
OBS! detta är en standard tank och behöver ej vara exakt levererad.
