Efficient Networks SpeedStream 5200 Series Quick Start Guide

SpeedStream 5200 Series Bridge
10
1010
10 Product Specifications and Support
SpeedStream 5200 Series Bridge Back Panel
SpeedStream 5200 Series Bridge Back PanelSpeedStream 5200 Series Bridge Back Panel
SpeedStream 5200 Series Bridge Back Panel
The back panel contains all DSL, Ethernet, console, and power interfaces.
Table 2: 5200 Back Panel Interfaces
From left to right:
Power The bridge uses a standard AC power cord and has an
ON/OFF switch
DSL Port DSL connectivity is through this 8-pin, RJ-45 port.
Ethernet Ports One Ethernet 10Base-T port (8 pin, RJ-45)
Console Port Asynchronous RS232 connectivity is through this 8 pin,
RJ-45 port (support only).
CONSOLE

Efficient Networks SpeedStream 5200 Series Specifications

General

Brand	Efficient Networks
Model	SpeedStream 5200 Series
Category	Modem
Language	English
