Efitment IC035 - Assembly Instruction Step 3; Step 3: Seat Post and Seat Attachment

7
ASSEMBLY INSTRUCTIONS
STEP 3：
Attach the Seat Slider (No.30) to the Seat
Post (No.31), tighten and secure with Washer
(No.33) and Knob (No.34).
Attach the Seat (No.29) to the Seat slider
(No.30), tighten and secure with Spanner
(No.95).
Assembly is complete!
81
#95 S13-14-15 1PC
S13
#33 d10*Φ30*2.5 1PC
#34 M10*Φ58*32 1PC
13
30
33
31
34
29
