Efka AB620A - Installing the Housing (AB600 A)

- AB600A /AB611A /AB620A
P a g e | 15
3.5 Installing the housing
 Slide the side housing cover carefully on the controls.
Note: Make sure that the proper seating of the housing is guaranteed.
 Tighten the 4 screws (Torx T20) of the side housing.
M4x42, 1+0,5 Nm
M4x16, 1+0,5 Nm
M4x10, 1+0,5 Nm
