Efka DC 1550 - Page 25

EFKA AB320A5200
27
Adapter cord for YAMATO chainstitch machines VC series
Setting the functional sequence Thread trimming mode ! Set parameter 290 = 5
Setting the functions of the keys Input in1 ! Set parameter 240 = 7
Adapter cord for YAMATO chainstitch machines VG series
Setting the functional sequence Thread trimming mode ! Set parameter 290 = 5/21
Setting the functions of the keys Input in1 ! Set parameter 240 = 7
*) Rear view (soldering side) of 37-pin plug (ST2). Front view (component side) of the remaining plugs/sockets.
