Efka DC 1550 - Position of the Socket Connectors

EFKA AB320A5200
9
4.2 Position of the Socket Connectors
B2 Socket for sensors
B18 Socket for light barrier module
B41 Socket for motor power supply
B80 Socket for actuator
B776 Socket for V810/V820 control panel
ST2 Socket for solenoid inputs and outputs /
solenoid valves / displays / keys and switches
B41
M
B18
KL2333
ST2
L S M ...
B2
B41
B2
B18
M
B776
ST2
V8 . .
B80
B776
EB ...
B80
