EFKA AB320A5200
57
Supplier Level
Mode !
!!
! 0 2 3 4 5 6 7 8 9101415161720212324
Parameter
200 - ---------------50-
201 - --160-----------200--
202 - ------00-------80-
203 - --350------------200-
204 - --------12--------
** 205 - - - - - - - - - 240 - - - - - - 100 -
206 - - - - - - - - - 150 - - - - - - 50 -
207 - ---------------10-
209 - - - - - - - - - 100 - - - - - - - -
210 - ---------------100-
211 - ---------------0-
212 - - - 100 - - - - - 100 - - - - - - - -
213 - --------12-100----50-
234 - ------00---------
240 - - - 6 - - - 6 6 - - - 15 - 13 - 13 6
241 - - - - - - - - - - 16 - - - - - 07 14
242 - --3---1038-----31-0128
243 - - - - - - - 1 34 - - 14 15 - 32 - 0 22
244 - ----------15----16-
245 - ------1212-----16-0-
246 - -------------13-33-
247 - ---------------11-
248 - --------------1428-
249 - ---------------17-
250 - ---------------400-
**253 - -------------0-0-
255 - --25-----25--------
260 - --------------100--
262 - --------------20--
269 - -------25---------
270 - -------1-3----1--
271 - - - - - - - - - - 200 - - - - 4 - -
272 - -----------------
**274 - -----------0-----
** 275 - - - - - - - - - - - - 100 - - - - -
** 280 x x x 100 - - 100 x x x - 10 - 100 - x - 100
** 281 - - - - - - - - - 280 - 50 1000 - - 250 - -
** 282 x 0 x 0 - - 200 x x x x 30 200 - - 40 - -
** 283 - - - 200 - - - - - - - 100 - - - 80 - -
** 284 x x x - - 0 0 x x 150 x - 0 - - 300 - 230
** 285 x x x - - - - x x 70 x - - 70 - 680 - -
** 286 x x x x - 0 0 x x x x 100 0 - - - - -
** 287 x x x x - - 0 x x x x 50 0 - - - 0 -
** 288 x x x - - - - x x x x - - 200 - - - -
291 - - - -55877 - -775 -5 -5
292 - - - -33555 - -573 -3 -3
293 - -----------------
294 - ----------14------
Further Functions Switchable by Means of the Control Keys
Mode !
!!
! 0 2 3 4 5 6 7 8 9101415161720212324
Basic pos.1 11122222112221112
Single OFF OFF OFF ON ON ON ON OFF OFF OFF OFF ON ON OFF OFF OFF OFF OFF
start
backtack
Double ON ON ON OFF OFF OFF ON OFF OFF ON ON ON OFF OFF ON ON ON OFF
start
backtack
Single OFF OFF OFF ON ON ON ON OFF OFF OFF OFF ON ON OFF OFF OFF OFF OFF
end
backtack
Double ON ON ON OFF OFF OFF ON OFF OFF ON ON ON OFF OFF ON ON ON OFF
end
backtack
Note
The preset values of the following list of parameters refer to the setting of parameter 290 = 0.
x = The positions marked with ”x“ are not used in the functional sequence!
- = For the positions marked with “-“ the preset values listed in the List of Parameters are used !
** = When programming the 3-digit or 4-digit control parameter values (without control panel), the 2-digit or 3-digit
value displayed must be multiplied by 10.
