o Unlock the position of the seat post by opening the
quick release lever. Lower the seat post to the
desired riding position, then securely clamp the seat
post quick release.
o Refer to the instructions for the operation of the seat
post quick release on Page 17.
To remove the battery:
o Loosen the seat post clamp quick release lever by
rotating the lever to the OPEN position. (See photo.)
o Elevate the seat/seat post/battery assembly all
the way to the top-most extent of its travel,
exposing the battery ‘shoe’ to which the battery is
connected. (See photo.)
o Close the seatpost quick release lever to lock the
shoe in place. Gently tap the battery toward the
front of the bike to disconnect the battery from
the connector in the shoe. Remove the battery.
Currie Tech Technical and Customer Service: +1 800-377-4532
