56 VOLT LITHIUM-ION REAR MOTOR BIKE-HANDLE BRUSHCUTTER — BC3800E12
DESCRIPTION
KNOW YOUR Brushcutter (Fig. A)
1. Speed Limiting Lever
2. Lock-off Lever
3. Wing Bolt
4. Trigger
5. Bike Handle
6. Shaft
7. Cutting Line
8. Guard Assembly
9. Trimmer Head
10. Sealing Screw
11. Shaft-locking Hole
12. Guard Accessory
13. Multi-Function Wrench
14. Hex Wrench
15. 3-teeth Blade
16. Outer Flange
17. Nut
18. Release Button
19. Rubber Pad Protection
20. Latch
21. Electric Contactsms
22. Ejection Mechanism
23. Strap Buckle
24. Hip-pad
WARNING: Never operate the tool without the
guard rmly in place. The guard must always be on the
tool to protect the user.
WARNING: When the tool is equipped with a
trimmer head, the guard accessory with line–cutting
blade should be mounted onto the guard. Failure to
comply will result in overly long cutting line and overload
the motor. Never use the trimmer head without guard
accessory.
ASSEMBLY
WARNING: If any parts are damaged or missing, do
not operate the brushcutter until the parts are replaced.
Use of the brushcutter with damaged or missing parts
could result in serious personal injury.
WARNING: Do not attempt to modify the brushcutter
or create accessories not recommended for use with this
product. Any such alteration or modication is misuse and
could result in a hazardous condition leading to possibly
serious personal injury.
WARNING: Always wear heavy gloves when
installing or removing the guard and doing any
maintenance on the 3-teeth blade/line-cutting blade. Be
careful of the line-cutting blade on the guard accessory /
3-teeth blade for protecting your hands from being injured
by both the blades.
WARNING: To prevent accidental starting that could
cause serious personal injury, always remove the battery
pack from the tool when assembling parts or transporting
the machine.
WARNING: Never operate the tool without the guard
and bike handle rmly in place. Failure to comply could
result in possible serious personal injury.
MOUNTING AND ADJUSTING THE BIKE HANDLE
The brushcutter is stored as shown in Fig. B. Firstly,
loosen the wing bolt on the connecting joint and then lift
the bike handle 180° around the shaft (Fig. C), turn it 90°
anticlockwise to make it face the bump head (Fig. D).
Lastly, move it back and forth to achieve a comfortable
working position and tighten the bolt.
NOTICE: Operating the machine with the bike handle
perpendicular to the shaft is only permitted.
MOUNTING THE GUARD
1. Lift the cutting head and face it downward; align the two
mounting holes in the guard with the two bolts that are
preassembled on the base of shaft. Make sure that the
internal surface of the guard faces towards the cutting
head (Fig. E).
2. Lock the guard in place with the bolts and the supplied
hex wrench (Fig. F).
REPLACE THE TRIMMER HEAD WITH THE 3-TEETH
BLADE
Know the trimmer head Fig. G and follow the steps as
Fig. H-1 - Fig. H-4 shown (refer to the section “line replace-
ment”) to disassemble the trimmer head. To mount the
blade follow the steps below:
1. To mount the metal blade unit (Fig. I).
2. Remove the guard accessory by loosening the three
screws with washer (Fig.J).
To Next Page
