3. The blade is shipped with a sheath. Before mounting
the blade onto the brushcutter, the sheath should be
removed by undoing the clamp wire from the hook on
the sheath (Fig. K).
NOTICE: To protect against injury, you have to wear
gloves prior to any operation with the 3-teeth blade.
4. Rotate the motor shaft to align the slot in the inner ange
with the shaft-locking hole in the gear case (Fig. L).
5. Insert the hex wrench into the aligned holes to act as a
STABILISER (Fig. M).
6. Mount the blade onto the motor shaft, ensuring
that the suface of the blade is ush with the
surface of the inner ange bulge. Mount the outer
ange and the nut (Fig. N). Pre-tighten the nut in a
COUNTERCLOCKWISE direction by hand.
7. Position the gear case against a solid surface for
support. With one hand hold the brushcutter shaft
and the other hand grasp the multi-function wrench
to tighten the nut following the directional arrow icon
marked on the outer ange (Fig. O).
USE OF GUARD ACCESSORY
NOTICE:
When the brushcutter is equipped with a trimmer
head, the guard accessory must be mounted onto the guard.
Secure the guard accessory onto the guard by tightening
the three screws with the hex wrench due to the line-
cutting blade is equipped on the guard accessory. Failure
to comply could result in an overly long cutting line and
motor overload.
OPERATION
WARNING: Do not allow familiarity with this product
to make you careless. Remember that a careless fraction
of a second is sufcient to inict serious injury.
WARNING: Always wear eye protection, along with
hearing protection. Failure to do so could result in objects
being thrown into your eyes and other possible serious
injuries.
WARNING: Do not use any attachments or
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious personal injury.
APPLICATIONS
You may use the brushcutter for the purpose listed below:
◾ With 3-teeth metal blade: Cutting grass, weeds,
wild growth and scrub, thinning young trees with a
maximum stem diameter of 2cm.
◾ With Trimmer Head: Trimming grass and weeds from
around porches, fences and decks.
NOTICE: The tool is to be used only for its prescribed
purpose. Any other use is deemed to be a case of misuse.
ATTACHING/DETACHING THE BATTERY PACK
Fully charge before rst use.
To Attach
Align the battery rib with the mounting slots and press the
battery pack down until you hear a “click” (Fig. P).
To Detach
Depress the battery-release button and the battery pack
out (Fig. Q).
MOUNT THE DOUBLE-SHOULDER STRAP AND
HOLDING THE MACHINE
Put the double-shoulder strap on your body and insert
the two parts of the strap buckle into each other until a
click is heard (Fig. R-1). Align the hook of hip pad into hole
of the tubing clip xed on the shaft, and press the shaft
down softly (Fig. R-2 & R-3 & R-4).
Hold the line trimmer with both hands on the right side of
your body (Fig. S). The trimmer head or blade should be
parallel to the ground at a proper cutting distance without
the operator bending over.
Releasing the brushcutter can be achieved in two ways;.
Release the strap buckle (Fig. T) or press the hook of the
strap and take it apart from the tubing clip xed on the
shaft (Fig. R-2).
WARNING: When emergency occurs, take it off from
your shoulder immediately, no matter what way the strap
is in. Releasing the strap buckle (Fig. T) and both hands
taking off your shoulders at each side is a quick release
method.
WARNING: You should not use the single-shoulder
strap and double-shoulder strap simultaneously.
