56 VOLT LITHIUM-ION REAR MOTOR BIKE-HANDLE BRUSHCUTTER — BC3800E14
STARTING/STOPPING THE Brushcutter
To Start
Press down the lock-off lever and hold it in that position.
Depress the trigger to start (Fig. U).
Different pressure on the trigger results in variable
rotating speed of the cutting unit. If necessary, adjust the
speed limiting lever to set the maximum speed.
NOTICE: The speed limiting lever can also be preset to
limit the trigger travel.
To Stop
Release the trigger.
NOTICE: The motor runs only when the lock-off lever and
trigger are both pressed.
WARNING: Always remove the battery pack from the
line trimmer during work breaks and after nishing work.
USING THE MACHINE
WARNING: Dress properly to reduce the risk of
injury when operating the brushcutter. Do not wear loose
clothing or jewelry. Wear eye and ear/hearing protection.
Wear heavy duty, long trousers, boots and gloves. Do not
wear short trousers, sandals or go barefoot.
Before operating, look around you to ensure a safety work-
ing area without other people, animals or any loose objects.
Make sure they are at least 15m away. And then check for
eye protection, proper clothing and balanced footing.
Before each use check for damaged/worn parts.
Check the trimmer head, 3-teeth blade, guard, guard
accessory, bike handle and double-shoulder strap and
replace any parts that are cracked, warped, bent, or dam-
aged in any away. The line-cutting blade on the edge of
the guard accessory can dull over time. It is recommend-
ed that you periodically sharpen it with a le or replace it
with a new blade.
After each use, clean the brushcutter
USING WITH TRIMMER HEAD
Adjusting cutting line length
The trimmer head allows the operator to release more
cutting line without stopping the motor. As line becomes
frayed or worn, additional line can be released by lightly
tapping the bump knob on the ground while operating the
trimmer (Fig. V).
NOTICE: Line release will become more difcult if the
cutting line becomes too short.
WARNING: Do not remove or alter the line-cutting
blade assembly. Excessive line length will cause the mo-
tor to overheat and may result in serious personal injury.
Line Replacement
NOTICE:
Always use the recommended nylon cutting
line with a diameter that does not exceed 2.4 mm. Using
line other than that specied may cause the brushcutter
to overheat or become damaged.
WARNING: Never use metal-reinforced line, wire,
or rope, etc. These can break off and become dangerous
projectiles.
1. Remove the battery pack.
2. Remove the remaining cutting line, if necessary.
3. Rotate the spool retainer in the direction indicated by the
arrow, as necessary, to align the LOAD line on the spool
retainer with the eyelets in the spool base (Fig. W-1).
4. Cut 5m of cutting line, and insert the line into the
mounting hole inside the eyelet (Fig. W-2). Push and
pull the line from the other side until equal amounts
of line appear on both sides of the spool (Fig. W-3).
5. Press, while rotating the spool retainer in the arrow
direction, to wind the line onto the spool until
approximately 14cm of line is showing on each side
(Fig. W-4).
6. Push the spool retainer down while pulling on the
lines to manually advance the line and to check for
proper assembly of the trimmer head.
When the cutting line breaks from the line outlet or the
cutting line is not released when tapping the trimmer
head, follow the steps below:
1. Remove the battery pack.
2. Press the release tabs on the spool retainer and
remove the spool retainer by pulling it straight out
(Fig. H-1 & H-2).
3. Remove the cutting line from the spool retainer.
4. With one hand holding the spool base, use the other
hand to grasp the spool retainer and align the tabs
on the spool retainer with the holes in the spool base
(Fig. X-1); use your palm to press and rotate the
spool retainer left and right until the tabs lock with
the spool base (Fig. X-2).
5. Reload the cutting line.
