EDGER ATTACHMENT — EA0800/EA0800-FC18
All edger service, other than the items listed in these maintenance instructions, should
be performed by competent edger service personnel.
REPLACING THE BLADE
WARNING: Do not attempt to straighten or weld a bent or cracked blade. Such
a blade may break and it must be replaced. Recommend replace only with EGO edger
blade, see “Recommended Blade” section.
NOTICE: Replace the blade if its length
is no longer sufficient to maintain the
necessary ground clearance and obtain
the required depth of cut.
WARNING: Always protect
your hands by wearing heavy gloves
or wrapping the blade with rags or
other materials when performing any
maintenance on the edger blade.
Removing the blade
1. Stop the motor and remove the
battery pack.
2. Lay the edger on its back so that the
blade is facing upwards.
3. Wear protective gloves. Use a
needle nose pliers (not included)
to remove the cotter pin from the
motor shaft (Fig.8).
4. Rotate the blade to align the slot in the flange with the hole in the gear case
(Fig. 8).
5. Insert the hex wrench provided into the aligned holes to act as a stabilizer. Use
the multi-function wrench provided to loosen the nut CLOCKWISE (Fig.9).
8
Aligned Shaft-locking Holes
Gear Case
Inner Flange
9
Stabilizer
Multi-function
Wrench Provided
Cotter Pin
To Next Page
