56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2000E
16
OPERATION
ASSEMBLING THE GRASS BAG
1. Check the grass bag before assembling to make sure there is no damage.
2. Slide the grass bag onto the frame (Fig. 2).
3. Assemble the top clips to the frame (Fig. 3), then assemble the two side
clips. Assemble the bottom clip last.
4. The completely assembled grass bag is shown in Fig. 4.
2
3
4
Clips
