3. Take out the micro switch and cable from the bottom housing.
4. Replace with a new switch if it shows malfunction.
5. Test the micro switch.
• Leave the trigger of the micro switch unpressed. Turn on the mower, the mower should
be turned on properly.
• Depress the trigger, the mower should stop running.
4(4)A 250V~5E4 TUV/CE,6(6)A
125V~5E4 UL/CUL
Open the Right Beam Housing
