EGO LM2000E Repair Guide Line

6. Insert the left/right tube assembly into the outer tube. Pay attention left and right inner tubes
are not interchangeable, left inner tube should be fixed in the left outer tube, and right inner
tube should be in the right outer tube.
Left inner tube ASSY
Right inner tube ASSY
Opening in the left of
the plastic sleeve
Opening in the left of
the plastic sleeve
Opening in the right of
the plastic sleeve
Opening in the right of
the plastic sleeve
To Replace the Left/Right Inner Tube ASSY/Beam Tube
131
