3. Disconnect the flat flexible cable (FFC)
a) The FFC and the plug is located at back of the power indicator, it can be unplugged from
the opening of the battery compartment (Fig. 9).
b) Press the sides of the connector and remove the plug from the socket (Fig. 10).
Housing Cover Assembly Replacement
Disassembly
9
10
21
