EGO LM2000E - Page 39

3. Take out the battery cover from the opening of the battery compartment (Fig. 1)
4. Draw the shaft out from the battery cover assembly (Fig. 2)
5. Replace with a new battery cover assembly; Fix the new one to the housing cover in reverse
order.
1 2
Description
Part Number
SPEC
Shaft
5670343000
φ5x167
Battery Cover Assembly
2823661000
---
Battery Cover Assembly Replacement
39
