Troubleshooting
Problem
Possible Cause
Fault Position
Indicator/ Headlight Display
Test & Solution
LED on
battery
pack
Power
indicator
on mower
Headlight
Fail to start
The side rails are not
fully extended and
locked by the green
clamps
Side Rails
GREEN
OFF
Can be
turned on
Fully extend the side rails and
lock the clamps, then test again.
3-pin plug
disconnection from PCB
PCBA
Open the housing cover, check
the 3-pin plug.
Disconnection of the
limit switch (micro
switch in the side rail)
Limit Switch
Open the right beam housing,
check the micro switch.
The battery pack was
not pressed in place
Battery
Compartment
OFF
OFF
Can’t be
turned on
Press until the battery pack snaps
into the compartment.
Disconnection of the
terminals that connect
the battery to main PCB
Terminals
between
battery and
PCBA
Take out the battery
compartment, check the three
terminals. If loosed, remove the
terminals, clamp them, then plug
them onto the contacts.
