PACKING LIST
PART NAME QUANTITY
Lawn mower 1
Grass bag 1
Grass bag frame 1
Mulching insert 1
Safety key 1
Operator’s manual 1
DESCRIPTION
KNOW YOUR MOWER (Fig. A & B & C)
1. Safety Button
2. Self-propel Trigger
3. Handle-locking Clamp
4. Rear Discharge Door
5. Rear Handle
6. Battery-pack Cover
7. LED Headlights
8. Front Handle
9. Front Wheel
10. Cutting-height Adjustment Lever
11. Mower Deck
12. Rear Wheel
13. Grass Bag
14. Quick-adjust Lever
15. Side Rail
16. Self-propel Speed-control Lever
17. Bail Switch (Switch Lever)
18. Handle
19. Mulching Insert
20. Support for Upright Storage
21. Trailing Shield
22. Switch Button for LED Headlights
23. Power Indicator
OPERATION
ASSEMBLING THE GRASS BAG
1) Slide the grass bag onto the frame (Fig. D).
2) Assemble the top clips to the frame (Fig. E), then
assemble the two side clips. Assemble the bottom
clip last.
3) The completely assembled grass bag is shown in
Fig. F.
NOTICE: Under normal usage, bag material is subject to
wear. To reduce the risk of injury, frequently inspect the
bag assembly and replace if there are any signs of wear
or deterioration. Use only grass bags manufactured for
this mower.
ADJUSTING THE FOLDABLE HANDLE
WARNING: Do not attempt to start the mower until
the handle has been locked at one of the three preset
operating positions (UPPER OPERATING POSITION, MIDDLE
OPERATING POSITION and LOWER OPERATING POSITION).
Your mower is shipped with the handle in the compact,
LOCKED STORAGE POSITION (Fig. G).
1) Press and hold the quick-adjust lever to release the
handle from the LOCKED STORAGE POSITION.
2 Lift the handle from its folded position, then release
the lever. Gently pivot the handle upward until you hear
and feel the lock pin engage in one of the following
different positions as shown in the.
◾ GRASS BAG ATTACHMENT/REMOVAL POSITION
◾ UPPER OPERATING POSITION
◾ MIDDLE OPERATING POSITION
◾ LOWER OPERATING POSITION
