◾ To Remove the Blade
Following Fig. T.
NOTICE: If the bolt rotates with the motor shaft when
loosening the bolt, turn the fan by hand to align the
through holes in the fan with the holes in the blade, and
place another metal rod into the aligned holes (Fig. U).
◾ To Install the Blade
Following the assembly sequence in Fig. V , with the
fan blade towards deck and the printed blade side
towards outside, align the through holes in the fan with
the holes in
the blade (Fig. W) and then tighten the
blade as Fig. X shown.
NOTICE: The recommended torque for tightening the
blade bolt is 49-59Nm.
STORING THE MOWER
◾ Remove the battery pack from the mower and store it
in a cool, dry and clean location. Do not store it next to
corrosive materials, such as fertilizer or rock salt.
◾ Lubricate the mower.
◾ Store the mower in a covered, enclosed space, that is
cool and dry and out of the reach of children.
◾ Do not cover the lawn mower with a solid plastic sheet.
Plastic coverings trap moisture around the mower,
which causes rust and corrosion.
◾ The mower can be stored upright or at. (Fig. Y).
WARNING: If the mower begins to tip over from the
upright position, mower damage or personal injury may
result. Always keep the mower stable and out of the reach
of children when it is in the upright position. If possible,
lay it at for storage.
Protecting the environment
Do not dispose of electrical appliances as
unsorted municipal waste, use separate
collection facilities.
Contact your local government for
information regarding the collection
systems available.
If electrical appliances are disposed of in
landlls or dumps, hazardous substances
can leak into the groundwater and get into
the food chain, damaging your health and
well-being.
