56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2100SP/LM2100SP-FC/LM2100/LM2100-FC 47
The handle assembly can be folded away completely for storage:
1. Remove the grass bag.
2. Move the cutting-height adjustment lever toward the front and engage it in the
lowest setting (setting 1).
3. Open the handle-locking clamps
and fully recess the side rails to the
compact position.
4. Press and hold the quick-adjust
lever with your right hand to release
the handle. Gently pivot the handle
toward the front of the mower;
release the quick-adjust lever
and continue to pivot the handle
until you hear and feel the lock
pin engage in the locked storage
position.
5. Store the mower upright or at
(Fig. 37a & 37b).
WARNING:
If the mower to tips
over from the upright position, mower
damage or personal injury may result.
Always keep the mower stable and out
of the reach of children when it is in the
upright position. If possible, lay it at for
storage.
37a
37b
