56-VOLT LITHIUM-ION TELESCOPIC POWER POLE — PPX1000/PPX1000-FC 15
ATTACHING THE SHOULDER
STRAP (Fig. 3)
Depress the strap hook to open it and
attach it onto the shoulder strap eyelet.
TELESCOPIC TUBE (Fig. 4)
The product is equipped with a telescopic
tube that could extend up to 37-3/4” (96
cm). The clamping knob is used to lock the
telescopic tube in position at any extended
length.
1. To extend the telescopic tube,
loosen the clamping knob by
following the arrow on the “unlock”
icon. The telescopic tube will slide
freely.
2. Pull the telescopic tube out to
desired length of extension.
3. To lock the telescopic tube in position, tighten the clamping knob by following the
arrow on the “lock” icon.
WARNING:
To prevent pinching of hands or ngers, extend and retract the
telescopic tube with caution.
3
Strap Hook
Shoulder Strap Eyelet
4
Indication for
Maximum Degree
Clamping Knob
