56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC 21
ADJUSTING THE FOLDABLE HANDLE
WARNING: Do not attempt to start the mower until the handle has been locked
at one of the three preset operating positions.
1. LOCKED STORAGE POSITION: Your
mower is shipped with the handle in
the compact, locked position
(Fig. 5).
2. GRASS BAG ATTACHMENT/
REMOVAL POSITION: Press and hold
the quick-adjust lever with your
right hand to release the handle
from the locked storage position.
Begin to lift the handle from its
folded position with your left hand,
and then release the lever (Fig. 5).
Gently pivot the handle upward
until you hear and feel the lock pin
engage in the first position (Fig. 6).
This position allows easy access to
install and remove the grass bag.
5
Press the Quick-
Adjust Lever
6
Grass Bag
Attachment/Removal
Position
Upper
Operating
Position
Lower
Operating
Position
Middle
Operating
Position
Locked Storage
Position
