56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2140SP/LM2140SP-FC 45
The handle assembly can be
folded away completely for
storage:
1. Remove the grass bag.
2. Move the cutting-height adjustment
lever toward the front and engage it
in the lowest setting (setting 1).
3. Open the handle-locking clamps
and fully recess the side rails to the
compact position.
4. Press and hold the quick-adjust
lever with your right hand to release
the handle. Gently pivot the handle
toward the front of the mower;
release the quick-adjust lever
and continue to pivot the handle
until you hear and feel the lock
pin engage in the locked storage
position.
5. Store the mower upright or flat
(Fig. 37a & 37b).
WARNING: If the mower to tips over from the upright position, mower damage
or personal injury may result. Always keep the mower stable and out of the reach of
children when it is in the upright position. If possible, lay it flat for storage.
37a
37b
