4356-VOLT LITHIUM-ION ELECTRIC LAWN TRACTOR — TR4200/TR4200-FC
DRIVING THE ELECTRIC LAWN TRACTOR (Fig. 18)
D
D
D
R
R
R
18
After starting the tractor, follow these instructions
◾
To drive straight forward, push the direction control lever forward in the “D” direction and hold the steering wheel
straight with no rotation. Control the driving speed with the accelerator pedal.
◾
To drive in reverse, pull the direction control lever backward in the “R” direction and hold the steering wheel
straight with no rotation. Control the driving speed with the accelerator pedal.
NOTE: When pulling the direction control lever from the “D” to “R” position WHILE driving forward, the tractor will
decrease its speed to zero and then shift in reverse. The “R” icon will illuminate on the LCD screen and the beep will
sound six times.
NOTE: When switching between forward and reverse during driving, move the direction control lever directly from
one end to the other without stopping in neutral position, otherwise the tractor may stop moving.
◾
To turn left, rotate the steering wheel to the left.
◾
To turn right, rotate the steering wheel to the right.
NOTICE: Rapid movement of steering wheel is not recommended as damage to the electric components of the tractor
may occur.
NOTICE: Aggressive turning can scuff or damage lawns. Perform turns at low driving speed.
