56-VOLT LITHIUM-ION ELECTRIC LAWN TRACTOR — TR4200/TR4200-FC52
Maintenance Service Interval Maintenance Procedure
Before storage
◾
Remove the batteries from the tractor.
◾
Remove the safety key from the tractor.
◾
Perform all maintenance procedures listed above and thoroughly clean the
tractor.
◾
Inspect the entire product for damaged, missing, or loose parts, replace or
tighten the corresponding ones before storage.
Annually
◾
Lubricate the shaft sleeves of the front wheels. Refer to chapter
“LUBRICATING THE SHAFT SLEEVES OF THE FRONT WHEELS”.
GENERAL MAINTENANCE
◾
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use clean cloth to remove dirt, dust, oil, grease, etc. Insect
repellent spray may damage plastic and painted surfaces. Do not spray insect repellent near the tractor.
◾
Prolonged exposure to sunlight will damage some surfaces.
◾
Once the tractor is left out in the rain accidentally, use dry clean cloth to dry the seat, control panel, etc., before you
restart it or store it.
WARNING: Do not at any time let brake fluids, gasoline, petroleum-based products, penetrating oils, etc., come in
contact with plastic parts. Chemicals can damage, weaken or destroy plastic which may result in serious personal injury.
Cleaning the machine
Remove any build-up of grass and leaves on or around the tractor housing. Wear eye protection and use compressed air
after each use to clean the tractor housing or the top side of the tractor.
The underside of the deck should also be cleaned using wash port after each use, as grass clippings, leaves, dirt,
and other debris will accumulate, especially when grass is wet or has high moisture content. This accumulation is
undesirable, as it will harden, restricting blade and air movement, probably resulting in a poorer quality of cut and even
promoting rust and corrosion.
Using wash port to clean the deck
NOTICE: Follow this procedure after EACH USE to prevent buildup and remove corrosive lawn chemicals.
IMPORTANT: You can wash the machine with a mild detergent and water. Do not pressure wash the machine. Avoid
excessive use of water, especially near the control panel, under the seat, around the motors and all electric components
and bearings.
1. Set the parking brake. Refer to section “SETTING THE PARKING BRAKE” in this manual.
2. Adjust the deck height to the lowest. Refer to section “Adjusting the cutting-deck height” in this manual.
3. Attach the supplied wash-port quick-coupler to garden hose.
To Next Page
