SNOW SHOVEL ATTACHMENT — SSA1200/SSA1200-FC18
LOUVER ADJUSTMENT KNOB
(Fig.4)
The direction of the snow discharge
can be changed by rotating the louver
adjustment knob. The snow discharge can
be directed to the left, straight ahead, or
to the right.
The maximum turn of the knob is 60°
(30° to the left or to the right).
Once the knob reaches the leftmost or rightmost position, it will get locked in that
position. To unlock it, press the knob down and rotate it toward the center. After
unlocking, the knob can be rotated again.
4
Louver
Adjustment
Knob
Lock
Indicator
