EGO ST1500 User Manual

56-VOLT LITHIUM-ION CORDLESS 15" BRUSHLESS STRING TRIMMER12
MOUNTING THE GUARD
WARNING:
Always wear gloves when mounting or replacing the guard. Be
careful of the blade on the guard and protect your hands from cutting.
1. Remove the battery pack from the trimmer.
2. Loosen the two bolts in the guard
with the M5 hex wrench; remove
the bolts and spring washers from
the guard (Fig. 3).
3. Lift the trimmer head and face it
downward; align the two mounting
holes in the guard with the two
assembly holes in the base of
the shaft. Make sure the internal
surface of the guard faces towards
the trimmer head (Fig. 4).
4. Lock the guard in place with the
bolts and the M5 hex wrench (Fig. 5).
3
4
5

EGO ST1500 Specifications

General

Cutting Swath	15 inches
Line Diameter	0.095 inches
Battery	56V Arc Lithium
Motor	Brushless
Line Feed	Bump Feed
Shaft	Straight
Power Source	Battery
Battery Included	No
Charger Included	No (available separately)
