56-VOLT LITHIUM-ION CORDLESS 15" STRING TRIMMER 15
MOUNTING THE GUARD
WARNING:
Always wear gloves when mounting or replacing the guard. Be careful
of the blade on the guard and protect your hands from being injured by the blade.
1. Remove the battery pack from the
trimmer.
2. Lift the trimmer head and face it
downward; align the two mounting
holes in the guard with the two bolts
that are preassembled on the base
of the shaft. Make sure that the
internal surface of the guard faces
towards the trimmer head (Fig. 4).
3. Lock the guard in place with the two
bolts and the supplied hex wrench
(Fig. 5).
4
5
