HARDWARE
VI.3. CONNECTORS OF EXCITER II CONNECTORS BOARD
J1 EURO DIN41612 2x32 pin a+c male right angle
a c
PIN № Signal Name PIN № Signal Name
1
BU+12V
1 BU+12V
2 BU+12V 2 VCC
3 VCC 3 VCC
4 N.C. 4 VCC3
5 VCC3 5 VCC3
6 VCC3 6 VCC3
7 VCC3 7 GND
8 GND 8 GND
9 GND 9 GND
10 DOUT0 10 DOUT1
11 DOUT2 11 DOUT3
12 DOUT4 12 DOUT5
13 DOUT6 13 DOUT7
14 GND 14 GND
15 DIN0 15 DIN1
16 DIN2 16 DIN3
17 DIN4 17 DIN5
18 DIN6 18 DIN7
19 DIN8 19 DIN9
20 DIN10 20 DIN11
21 GND 21 GND
22 T_TXD2 22 T_RXD2
23 T_TXD3 23 T_RXD3
24 T_TXD4 24 T_RXD4
25 T_TXD5 25 T_RXD5
26 T_TXD6 26 T_RXD6
27 T_TXD7 27 T_RXD7
28 T_TXD8 28 T_RXD8
29 GND 29 INTRUSION0
30 INTRUSION1 30 INTRUSION2
31 INTRUSION3 31 INTRUSION4
32 INTRUSION5 32 INTRUSION6
