HARDWARE
J2 POWER INPUT
MOLEX 4x2pin mini-fit Straight
PIN № Signal Name/Current PIN № Signal Name/Current
1 12V / 1.33A 5 12V / 1.33A
2 12V / 1.33A 6 GND / 1.25A
3 GND / 1.25A 7 GND / 1.25A
4 GND / 1.25A 8 24V / 1A
J3 INTRUSION SWITCHES
MOLEX 7x2pin Mini-fit Straight
PIN № Signal Name PIN № Signal Name
1 INTRUSION0# 8 GND
2 INTRUSION1# 9 GND
3 INTRUSION2# 10 GND
4 INTRUSION3# 11 GND
5 INTRUSION4# 12 GND
6 INTRUSION5# 13 GND
7 INTRUSION6# 14 GND
J6 Serial Ticket Printer COM9
MOLEX 3x2pin Mini-fit Straight
PIN № Signal Name/Current PIN № Signal Name/Current
1 COM9 Rx 4 +24V / 2A
2 COM9 Tx 5 EXT_DIN11 (Ticket Pr.BUSY)
3 GND / 2A 6 GND / 2A
J8 Serial Card Reader COM10
MOLEX 2x2pin Mini-fit Straight
PIN № Signal Name/Current PIN № Signal Name/Current
1 COM10 Rx 3 GND / 1A
2 COM10 Tx 4 +12V / 1A
J7 Serial Bill Acceptor COM6
MOLEX 2x2pin Mini-fit Straight
PIN № Signal Name/Current PIN № Signal Name/Current
1 COM6 Rx 3 GND / 1.5A
2 COM6 Tx 4 +12V / 1.5A
ATTACHMENTS
