14
• The electrical data of the pump must match the data of the power
mains. This data is found on the type plate, the packaging and in these in-
structions.
a
Aluminium casing
b
Casing cover
c
2 x cross-head screws M5 x 10 mm
d
UV-C bulb
e
Bulb fitting for UV-C
bulb
f
Ballast with mains cable
g
Screw sleeve
h
Hose connection
i
Union nut (hose safety)
j
Glass function
control window
k
Holder
l
4 x Fastenings screw for holder
A Definition
When unpacking, check that all parts have been included. For safety reasons, the UV-C bulb has been packed separately
and not assembled in the unit in order to prevent breakage during transport.
Unpacking
Read the operating and safety instructions carefully and comply with all instructions prior to assembly.
Open both cross-head screws
c
and lift up the casing cover
b
. Pull out the UV-C bulb fitting
e
. Carefully put the UV-C
bulb
d
into the fitting
e
until it audibly clicks in place. Carefully replace the fitting with the assembled UV-C bulb into the
casing and press down firmly. Replace the casing cover and screw down firmly.
CAUTION: Never operate UV-C bulbs outside the device.
UV-C radiation may damage the skin and eyes, even at low doses.
Fasten holder
k
and ballast
f
in a suitable location (e.g. in the cabinet beneath the aquarium) using the screws provided
and fix UV clarifier in the holder.
CAUTION: In order to avoid any water damage, remove the filtration equipment or circulation pump before fitting
the UV clarifier into the tubing system, ensuring that the piping system no longer contains any water.
Install the UV clarifier EHEIM reeflexUV on the discharge side (return water from external filter or from circulation pump).
Slip end of hose onto the hose connection
h
and secure with union nut
i
. Join the hose connection with the UV clarifier
by turning the screw sleeves
g
and tighten until hand-tight. Put filtration equipment or circulation pump back into operation.
Follow the manufacturer's operating instructions.
B Assembly
CAUTION: UV-C bulb contains mercury! Handle the UV-C bulb carefully DANGER OF BREAKAGE!
Do not touch the glass body directly with fingers. Be sure to use a soft cloth or similar material.
Plug the power socket into the mains to operate the UV-Clarifier EHEIM reeflexUV. Function control window
j
lights up in blue.
Initial start-up
CAUTION: Disconnect from the mains before servicing the device. In order to avoid any water damage when
cleaning and performing maintenance work, remove the filtration equipment or circulation pump before fitting
the UV clarifier into the tubing system, ensuring that the piping system no longer contains any water.
Cleaning: Disconnect the UV clarifier from the piping system by turning the screw sleeves
g
and removing from the
holder. Clean the glass tube inside the UV clarifier. Pull the EHEIM Universal Cleaning Brush (Order No.
4005570) through it several times.
C Cleaning and Maintenance
Maintenance:
The UV-C bulb has a maximum operating period of approx. 8,000 hours – this corresponds to about one
year – and must then be replaced.
C Cleaning and Maintenance
