EI 3016 - Page 38

38
Mode
Power up
Slide onto
mounting plate
Detecting fire
Activated
via interconnect
Pressing Silence
Button on Alarm
detecting fire
With the test button held the green LED will flicker/pulse every second
= LED on solid
= LED flashing
x 10mins
Standby
Testing
(monthly)
Press and hold
test button
x 1
Action Green LED
(power)
Yellow LED
(fault)
Red LED
(alarm)
Sound
Normal mode
In alarm mode
x 1 x 1
