DURING SCHEDULED MAINTENANCE
11 LITERS (Including Filters)
ENGINE MAIN OIL FILTER REPLACEMENT:
Unscrew the drain plug and remove oil from main oil filter casing.
After draining retighten the drain plug. Ensure to replace the Copper
gasket.
Unscrew the centre bolt and remove the filter casing along with
element.
Remove the used main oil filter element and clean the housing. Damage
and discard the same to avoid misuse.
Insert the centre bolt in its location of the casing.
Secure the spring driving through the centre bolt.
Locate the new filter element driving through the centre bolt.
Secure main oil filter o’ring with new and ensure its seating in its
location.
Tighten the centre bolt to specific torque (3 to 3.5 Kgf m / 29 to 34 N m).
CAUTION!
Cleaning and reuse of element is not recommended.
