USER MANUAL RETEVET™ PORTABLE ERG
T +49 7461 96 580 0 | F +49 7461 96 580 90 | export@eickemeyer.com | www.eickemeyer.com
Protocol ECVO 5-step single fl ash is a modifi ed version of the ECVO 5-step protocol described above. The difference is while
the ECVO 5-step uses 4 fl ashes in the DA 0.01 and DA 3.0 steps in order to used averaging to improve signal quality, this single
fl ash version only uses 1 fl ash to minimize testing time. Replicates can be made in both protocols, and artefactual results
deleted. This protocol is recommended for NON-anesthetized or NON- sedated animals.
ECVO 5-step single fl ash
Description Eye Flash Luminance Energy
(0.33, 0.33 white)
Background Luminance
(0.33, 0.33 white)
# Flashes
Dark-adaptation timer Both Off Off
Dark-adapted 0.01 Right 0.01 cd·s/m² @ 0.2 Hz Off 1
Dark-adapted 3.0 Right 3 cd·s/m² @ 1 / 15 Hz Off 1
Dark-adapted 10.0 Right 10 cd·s/m² @ 0.05 Hz Off 1
Dark-adapted 0.01 Left 0.01 cd·s/m² @ 0.2 Hz Off 1
Dark-adapted 3.0 Left 3 cd·s/m² @ 1 / 15 Hz Off 1
Dark-adapted 10.0 Left 10 cd·s/m² @ 0.05 Hz Off 1
Light adaptation timer Right Off 30 cd/m²
Light adapted 3.0 Right 3 cd·s/m² @ 2 Hz 30 cd/m² 20
Light adapted 3.0 fl icker Right 3 cd·s/m² @ 28.3 Hz 30 cd/m² 141 – 424
Light adaptation timer Left Off 30 cd/m²
Light adapted 3.0 Left 3 cd·s/m² @ 2 Hz 30 cd/m² 20
Light adapted 3.0 fl icker Left 3 cd·s/m² @ 28.3 Hz 30 cd/m² 141 – 424
Protocol ECVO short, yes / no protocol is a modifi ed version of the ECVO 5-step single protocol. Only the dark-adapted steps
are performed. This protocol is recommended for NON-anesthetized or NON-sedated animals when only rod- and mixed rod-
cone retinal function is required to be assessed.
ECVO short, yes / no protocol
Description Eye Flash Luminance Energy
(0.33, 0.33 white)
Background Luminance
(0.33, 0.33 white)
# Flashes
Dark-adaptation timer Both Off Off
Dark-adapted 0.01 Right 0.01 cd·s/m² @ 0.2 Hz Off 1
Dark-adapted 3.0 Right 3 cd·s/m² @ 1 / 15 Hz Off 1
Dark-adapted 10.0 Right 10 cd·s/m² @ 0.05 Hz Off 1
Dark-adapted 0.01 Left 0.01 cd·s/m² @ 0.2 Hz Off 1
Dark-adapted 3.0 Left 3 cd·s/m² @ 1 / 15 Hz Off 1
Dark-adapted 10.0 Left 10 cd·s/m² @ 0.05 Hz Off 1
