Never remove chips or splinters
when the machine is running.
Keep the machine out of child-
ren’s reach!
Persons below the age of 16
years are not allowed to use
the machine.
Use a detector to localize pipes
and/or cables in walls with con-
cealed electric, water or gas
lines.
Wear goggles and use a brea-
thing mask on dusty jobs.
The level of noise at the work-
place may exceed 85 dB(A). In
this case you will need to intro-
duce noise protection measu-
res for the user.
Repairs are to be carried out by
qualified electricians only.
Use only original replacement
parts.
Follow the general safety rules
for working with electric tools.
Wear goggles
Wear ear-muffs
Wear a breathing mask
5. Technical data
Mains voltage 230 V ~ 50 Hz
Power 750 W
Drilling capacity max. Ø in concrete 26 mm
in steel 13 mm
in wood 30 mm
Idle speed 0 - 880 rpm
Hammer rate 0 - 5180 min
Clamp neck Ø 43 mm
Sound pressure level LPA 94 dB(A)
Sound power level LWA 107 dB(A)
Vibration a
w
8,4 m/s
2
Totally insulated
Weight 3,5 kg
The noise from this electric tool was measured in
accordance with EN 50144-2-6.
The vibrations from this electric tool were measu-
red in accordance with EN 50144-2-6.
6. Preparations
6.1 General information
Use a detector to localize pipes and/or cables in
walls with concealed electric, water or gas lines.
Before you plug in the machine, check that your
mains voltage is the same as that marked on the
rating plate.
6.2 Fitting a bit (Figure 2)
The hammer drill comes with an SDS-Plus chuck.
Pull out the power plug!
Clean the shaft of the SDS-Plus drill bit (a) chisel
bit (14/15) or scroll chuck (13) and coat it with a
little machine grease before you insert it.
Pull back the locking sleeve (17) and hold in this
position while you insert the bit with a twist as far
as it goes into the SDS-Plus chuck (1).
Let go of the locking sleeve (17). The bit will auto-
matically be locked in place.
Pull on the bit to check that it is secure.
6.3 Removing a bit
Unplug the machine!
Pull back the locking sleeve (17).
Pull the bit out of the chuck (1).
