GB
8
Important!
When using equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating manual with due
care. Keep this manual in a safe place, so that the
information is available at all times. If you give the
equipment to any other person, give them these
operating instructions as well.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.
1. Safety information
Please refer to the booklet included in delivery for the
safety instructions.
CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
2. Layout (Fig. 1-6)
1. Miter stop
2. Parallel stop
3. Wheel guard
4. Cutting table
5. Water trough
6. Housing
7. Knurled screw for setting the angle
8. Scale for miter cut
9. Knurled screw
10. Thumb screw
11. Holder for splitter
12. On/Off switch
13. Switch housing
15. Diamond cutting wheel
16. Outer flange
17. Side cover
18. Nut
19. Splitter
20. Fastening screws for splitter holder
3. Technical data:
Motor rating: 600 W S2 10 min
Motor speed: 3000 rpm
AC motor 230 V ~ 50 Hz
Insulation material class Class B
Protection type IP 54
Protection class I
Cut length: Unlimited
Jolly length: Unlimited
Cutting height 90°: 35 mm
Cutting height 45°: 12 mm
Cutting table-Dimensions 330 mm x 360 mm
Diamond cutting wheel ø 180 x ø 25.4 mm
Weight: 10 kg
A load factor of S2 10 min (intermittent periodic duty)
means that you may operate the motor continuously
at its nominal power level (600 W) for no longer than
the time stipulated on the specifications label (10
minutes ON period). If you fail to observe this time
limit the motor will overheat. During the OFF period
the motor will cool again to its starting temperature.
Noise emission values
The noise generated by this equipment is measured
in accordance with DIN EN ISO 3744; 11/95. The
machine may exceed 85 db (A) at the workplace.
The user will require noise protection measures if
this is the case. (Wear ear-muffs!)
Idle speed
L
pA
sound pressure level 97.3 dB
L
WA
sound power level 110.3 dB
4. Important information
Please read the operating instructions carefully and
observe the information provided. It is important to
consult these instructions in order to acquaint
yourself with the equipment, its proper use and
safety regulations.
Important!
For safety reasons, the tile cutting machine is not to
be used by children, young people under 16 years of
age, or any other persons who are not acquainted
with these operating instructions.
