EINHELL DLST 9+1 User Manual

GB
- 13 -
h
e
g
l
l
ing
p
-
r
l
e
ic
r
of
e
-
e
n
ju-
d
e-
a
l
rial
4. Technical data
Max. permitted pressure: ........................... 12 bar
Hose length: .............................................. 9 +1m
Weight: .......................................................3.0 kg
5. Before starting the equipment
5.1 Assembly (Fig. 2)
The hose reel can be attached to a wall or ceiling
using either the suspension eye (5) or the angle
mount (4).
5.2 Connections
Hose (1) to the connection on the compressor
Hose (2) to the connection on the compressed air
tool
6. Operation
6.1 Rolling out
Pull out the hose (2) to the desired length from
the hose reel (3). The lock on the length of hose
is automatically activated if you let go of the hose
(2) and a grating sound is heard.
6.2 Rolling up
The lock can be released by a short pull on the
hose (2). Then feed the hose (2) evenly back into
the hose reel.
Warning! The lock produces a grating sound
when the hose is being unrolled or rolled up.
7. Cleaning, maintenance and
ordering of spare parts
7.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could at-
tack the plastic parts of the equipment. Ensu-
re that no water can seep into the device. The
ingress of water into an electric tool increases
the risk of an electric shock.
7.2 Maintenance
There are no parts inside the equipment which
require additional maintenance.
7.3 Ordering spare parts and accessories
Please provide the following information when
ordering spare parts:
•
Type of unit
•
Article number of the unit
•
ID number of the unit
•
Spare part number of the required spare part
For our latest prices and information please go to
www.isc-gmbh.info
Tip! For good results we
recommend high-quality ac-
cessories from
!
www.kwb.eu
welcome@kwb.eu
8. Disposal and recycling
The equipment is supplied in packaging to pre-
vent it from being damaged in transit. The raw
materials in this packaging can be reused or
recycled. The equipment and its accessories are
made of various types of material, such as metal
and plastic. Never place defective equipment in
your household refuse. The equipment should
be taken to a suitable collection center for proper
disposal. If you do not know the whereabouts of
such a collection point, you should ask in your
local council offi ces.
9. Storage
Store the equipment and accessories in a dark
and dry place at above freezing temperature. The
ideal storage temperature is between 5 and 30
°C. Store the electric tool in its original packaging.
Anl_DLST_9_1_SPK9.indb 13Anl_DLST_9_1_SPK9.indb 13 11.04.2019 13:53:2311.04.2019 13:53:23

EINHELL DLST 9+1 Specifications

General

Product color	Black, Grey, Orange
Maximum operating pressure	12 bar

Weight and Dimensions

Weight	2800 g
Hose length	10 m
Package depth	300 mm
Package width	275 mm
Package height	155 mm
Package weight	3500 g
