14
GB
3. Items supplied
Open the packaging and take out the equipment
with care.
Remove the packaging material and any
packaging and/or transportation braces (if
available).
Check to see if all items are supplied.
Inspect the equipment and accessories for
transport damage.
If possible, please keep the packaging until the
end of the guarantee period.
IMPORTANT
The equipment and packaging material are not
toys. Do not let children play with plastic bags,
foils or small parts. There is a danger of
swallowing or suffocating!
Air hammer screwdriver
Nipple
Extension attachment
Special compressed air oil
Plug-on attachments (10 items)
Original operating instructions
4. Intended use
The hammer screwdriver is a handy, pneumatically
operated tool designed for DIY applications and in
the automotive field.
It is suitable for fastening and releasing threaded
connections on motor vehicles (fitting tyres, etc.), as
well as in the agricultural sector.
The exhaust air emerges via the trigger lever (2)
towards the bottom.
The plug-on attachments (9) can be changed easily
and quickly. The compressed air supply is connected
via a nipple and a quick-lock coupling.
The equipment is to be used only for its pre-scribed
purpose. Any other use is deemed to be a case of
misuse. The user/operator and not the manufacturer
will be liable for any damage or injuries of any kind
caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
equipment is used in commercial, trade or industrial
businesses or for equivalent purposes. Only allow
repairs and services to be carried out by authorized
professional repair shops.
Remember.
Too small a diameter of the hose and too long a
hose line will result in loss of power.
5. Technical data
Max. loosening torque 312 Nm
Working range (max. thread size) M14
Max. permitted operating pressure 6.3 bar
Idling speed 7,250 min
-1
Square drive mount 12.7 mm (1/2 inch)
Air consumption at 6.3 bar 310 l/min
Recommended hose diameter Ø 10 mm
Recommended hose length 10 m
Weight 2.2 kg
Sound and vibration
Sound and vibration values were measured in
accordance with ISO 15744 and ISO 28927-2.
L
pA
sound pressure level 84.4 dB(A)
K
pA
uncertainty 3 dB
L
WA
sound power level 95.4 dB(A)
K
WA
uncertainty 3 dB
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Vibrations
Vibration emission value a
h
= 3.3 m/s
2
K uncertainty = 0.82 m/s
2
Additional information
Warning!
The specified vibration value was established in
accordance with a standardized testing method. It
may change according to how the equipment is used
and may exceed the specified value in exceptional
circumstances.
The specified vibration value can be used to
compare the equipment with another tool.
The specified vibration value can be used for initial
assessment of a harmful effect.
