EINHELL GC-PM 46/1 S HW B&S User Manual

GB
- 21 -
Danger!
Sound and vibration
L
pA
sound pressure level ........................ 90 dB(A)
K
pA
uncertainty .............................................3 dB
L
WA
sound power level ........................... 98 dB(A)
L
WA
sound power (measured) .............. 92.9 dB(A)
K
WA
uncertainty ..........................................5.1 dB
Wear ear-mus.
The impact of noise can cause damage to hea-
ring.
Vibration emission value a
h
= 5.9 m/s
2
K uncertainty = 2.4 m/s
2
Long work periods should be avoided due to the
development of high noise and vibration levels.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment’s construction and layout:
1. Damage to hearing if no suitable ear protec-
tion is used.
2. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
5. Before starting the equipment
5.1 Assembling the components
Some parts of the equipment come disassem-
bled. For quick and easy assembly, read and
follow the instructions below.
Note! You will need the following additional tools
(not supplied) for assembly, and also for mainte-
nance work:
•
One flat oil drip tray (for changing the oil)
•
One 1 liter measuring jug (oil/petrol resistant)
•
One petrol can
•
One funnel (suitable for the tank’s petrol filler
neck)
•
Household wipes (to wipe up oil/petrol resi-
due; dispose of these at a filling station)
•
One petrol suction pump (plastic, available
from DIY stores)
•
One oil can with hand pump (available from
DIY stores)
•
Engine oil
Assembly
1. Fit the lower and upper push bar (Item. 3) as
shown in Fig. 3a-3c. For fastening choose
one of the holes to suit the required height of
the push bar.
Important! The identical height must be set
on both sides.
2. Insert the grip of the starter cable (Item 9) into
the hook provided for that purpose as shown
in Fig. 3d.
3. Fasten the actuator cables to the push bar
with the supplied cable clips (Item 10) as
shown in Fig. 3e.
4. Lift the ejector ap (Item 5a) with one hand
and hook in the grass bag (Item 4a) as shown
in Fig. 4a.
5.2. Adjusting the cutting height
Warning! Adjust the cutting height only when
the engine has been switched o.
•
The cutting height is centrally adjusted with
the cutting height adjustor lever (Fig. 7/Item
8). Different cutting heights can be selected.
•
Actuate the adjustor lever and pull it to the
required position. Let the lever click into po-
sition.
Anl_GC_PM_46_1_51_1_S_HW_BS_SPK7.indb 21 17.09.14 10:41

EINHELL GC-PM 46/1 S HW B&S Specifications

General

Type	Walk behind lawn mower
Cooling type	Air
Cutting width	460 mm
Cutting system	Cylinder blades
Ergonomic handle	Yes
Number of wheels	4 wheel(s)
Fuel tank capacity	0.8 L
Recommended lawn area	1400 m²
Maximum cutting height	85 mm
Minimum cutting height	25 mm
Grass collecting volume	65 L
Cutting clearance adjustment	6
Power source	Gasoline

Weight and Dimensions

Weight	- g
