7.3 Preparing the mower for long-term
storage
Warning! Do not empty the petrol tank in enc-
losed areas, near re or when smoking. Petrol
fumes can cause explosions and re.
1. Drain the petrol tank using a petrol extraction
pump.
2. Start the engine and run it until the tank and
fuel line are completely empty and the engine
stalls.
3. Change the oil after each season.
4. Remove the spark plug. Use an oil-can to ll
the cylinder with approx. 20 ml of oil. Slowly
pull back the starter handle, which will bathe
the cylinder wall with oil. Screw the spark plug
back in.
5. Clean the cooling ns of the cylinder and the
housing.
6. Be sure to clean the entire equipment to pro-
tect the paint.
7. Store the equipment in a well-ventilated
place.
7.4 Preparing the mower for transport
Warning! Do not empty the petrol tank in enc-
losed areas, near re or when smoking. Petrol
fumes can cause explosions and re.
1. Drain the petrol tank using a petrol extraction
pump.
2. Always let the engine run until it has used up
the remainder of petrol in the tank.
3. Empty the engine oil from the warm engine.
4. Remove the spark plug connector from the
spark plug.
5. Clean the cooling ns of the cylinder and the
housing.
6. Unhook the starter cable from the hook (Fig.
3c). Slacken the connection shown in Fig. 3b
on the left and right of the push bar and swing
down the upper push bar. Make sure that the
actuator cables do not get kinked when the
bar is pulled up.
7. Wedge a few layers of corrugated cardboard
between the upper and lower push bars and
the engine in order to prevent any chang.
8. Secure the load suciently so that it cannot
slip and cause damage or injuries during
transportation.
7.5Consumables,wearmaterialsandspare
parts
Spare parts, consumables and wear materials
such as engine oil, V-belts, spark plugs, air lter
inserts, petrol lters, batteries and blades are not
covered by the warranty.
7.6 Ordering replacement parts:
Please quote the following data when ordering
replacement parts:
•
Type of machine
•
Article number of the machine
•
Identification number of the machine
•
Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
8. Disposal and recycling
The equipment is supplied in packaging to pre-
vent it from being damaged in transit. The raw
materials in this packaging can be reused or
recycled. The equipment and its accessories are
made of various types of material, such as metal
and plastic. Never place defective equipment in
your household refuse. The equipment should
be taken to a suitable collection center for proper
disposal. If you do not know the whereabouts of
such a collection point, you should ask in your
local council oces.
Anl_GC_PM_51_2_S_HW_SPK7.indb 27 30.09.14 08:12

EINHELL GC-PM 51/2 S HW Specifications

General

Type	Walk behind lawn mower
Motor type	Single cylinder OHV
Cooling type	Air
Cutting width	510 mm
Grass catcher	Yes
Product color	Black, Red
Cutting height	30 - 80 mm
Cutting system	-
Number of wheels	4 wheel(s)
Rotational speed	2900 RPM
Sound power level	98 dB
Fuel tank capacity	1.5 L
Handle(s) features	Ergonomic, Foldable, Soft grip
Engine displacement	173 cm³
Rear wheels diameter	280 mm
Sound pressure level	83.7 dB
Front wheels diameter	204 mm
Recommended lawn area	1800 m²
Maximum cutting height	80 mm
Minimum cutting height	30 mm
Grass collecting volume	70 L
Engine number of strokes	4
Cutting clearance adjustment	6
Power source	Gasoline

Weight and Dimensions

Weight	37800 g
Package depth	910 mm
Package width	580 mm
Package height	440 mm
Package weight	43500 g
